Concorde - G-BOAC (Manchester)

All, sorry for the lack of updates I've been deep in work at the moment so just doing some catch up.

Anyway here are some amazing photos of the Queen herself Concorde (G-BOAC) currently at Manchester.

If your in the area it's well worth a vist.

I'd like to thank the Runway Visitor Park for the amazing support and the very unique example they have looked after so well.

Concorde it's self it such a massive subject that I'll refrain from going into details but if you ever wanted the ultimate of engineering, design and flight here she is!

And YES she is a 'she'. The scale of the images do not it justice. In the blood it's a breathtaking sight!

Full profile with delta wings in shot.
Side Profile
Massive delta wing shown from the left side of the aircraft.
Inside the cabin from the most forward seat - Showing Speed in MPH and Outside Temp.
From a middle seat showing the very comforable leather seats. Each are £16,000 and are custom made.
Mid Section of the aircraft with the bottle of champange.
Flight Engineers Panel with macro on the electical configuration
Flight Engineers Panel but with focus on the fuel configuration
Overhead fault panel testing. Over exposed to see the text on the faults
Dials for the 4 Rolls Royce Olympus Engines
As John Hutchinson Said 'A proper cockpit!' Very correct statement sir!
Front landing gear.
From the right side of the delta wing directly infront of the intakes of engines 3/4
Truely massive hydraulic rams to support the weight.
Refueling contol panel for ground
Intakes for engine 3/4
'Engineered to be the best, Flew above the rest' Any pilot I've spoke to said Concorde was 100+ years in the future at retirement. A bit of a sad fact we went backwards.
Back end of the aircraft on engines 1/2
Her gorgeous tail.
Left delta wing with both engines 1/2 seen. Amazing G-BOAC
